10kW AC/DC EV Charging Module | High Efficiency Fast Charging Power Module
XNY 10kT-100100
The 10kW AC/DC EV Charging Module is a high-efficiency power conversion module designed for DC fast charging stations. Featuring up to 95% efficiency, DSP digital control, active PFC technology, hot-swappable design, and wide output voltage (200–750VDC), it delivers reliable, scalable, and stable charging performance for commercial EV charging infrastructure.
Quantity:
10kW AC/DC EV Charging Module
Product Description：
The10kW AC/DC EV Charging Module is designed for commercial DC fast charging stations, delivering efficient and reliable power conversion. With up to 95% efficiency, DSP digital control, active PFC technology, and a 200–750VDC output range, it ensures stable charging performance. Its compact, hot-swappable design and support for parallel operation make installation, maintenance, and system expansion simple and cost-effective.
Key Features：
- Up to 95% Efficiency – Reduces energy loss and operating costs.
- Wide Output Voltage (200–750VDC) – Compatible with various EV battery systems.
- DSP Digital Control – Ensures stable, accurate, and reliable charging.
- Active PFC Technology – Power factor ≥0.99 with low harmonic distortion.
- Hot-Swappable Design – Easy maintenance with minimal downtime.
- Parallel Expansion – Supports up to 60 modules for scalable charging systems.
- High Power Density – Compact design saves installation space.
- CAN Communication – Easy integration with smart EV charging systems
